2. Using GNATcheck

2.1. General GNATcheck Switches

The following switches control the general gnatcheck behavior

--version: Display Copyright and version, then exit disregarding all other options.
--help: Display usage, then exit disregarding all other options.
-P file: Indicates the name of the project file that describes the set of sources to be processed. The exact set of argument sources depends on other options specified, see below.
-U: If a project file is specified and no argument source is provided, process all units of the closure of the argument project. If explicit argument sources are specified directly through the command-line alongside the -U flag, they will be considered as closure roots for source fetching and not as explicit source files. If explicit argument sources are passed through -files, this option has no effect.
--no-subprojects: If a project file is specified and no argument source is explicitly specified (either directly or by means of -files option), process all the units of the root argument project. Otherwise this option has no effect.
-Xname=value: Indicates that external variable name in the argument project has the value value. Has no effect if no project is specified as tool argument.
--subdirs=dir: Use the specified subdirectory of the project objects file (or of the project file directory if the project does not specify an object directory) for tool output files. Has no effect if no project is specified as tool argument.
--no_objects_dir: Put gnatcheck output files in the current directory instead of using the project file’s object directory.
-eL: Follow all symbolic links when processing project files. By default, symbolic links are not resolved and kept as is. In some cases, resolving the target of symbolic links is needed for proper loading of project files.
--ignore-project-switches: Ignore gnatcheck switches specified in the package Check of the main project file.
--target=targetname: Specify a target for cross platforms, this is needed to locate the proper runtime library.
--RTS=rts-path: Specifies the default location of the runtime library.
-h: List all the rules checked by the given gnatcheck version.
-jnnnn: Use nnnn processes to analyze the source files. On a multi-core machine, this speeds up processing by analyzing subset of files separately under multiple processes running in parallel. If n is 0, then the maximum number processes is the number of core processors detected on the platform.

Attention

Please read the Performance and Memory Usage section before using this flag.
-l: Use full source locations references in the report file.
-log: Duplicate all the output sent to stderr into a log file. The log file is named gnatcheck.log. If a project file is specified as gnatcheck parameter then it is located in the project objects directory (or in the project file directory if no object directory is specified). Otherwise it is located in the current directory.
-mnnnn: Maximum number of diagnostics to be sent to stdout, where nnnn is in the range 0…1000; the default value is 0, which means that there is no limitation on the number of diagnostic messages to be output.
-q: Quiet mode. All the diagnostics about rule violations are placed in the gnatcheck report file only, without duplication on stdout.
-s: Short format of the report file (no version information, no list of applied rules, no list of checked sources is included)
-xml: Generate the report file in XML format.
-nt: Do not generate the report file in text format. Enforces -xml.
-files=filename: Take the argument source files from the specified file. This file should be an ordinary text file containing file names separated by spaces or line breaks. This switch can be specified only once, but can be combined with an explicit list of files. If you want to specify a source file with spaces, you need to surround it with double quotes ("). If a line in the file starts with -- then the whole line is ignored (considered as a comment).
--ignore=filename: Do not process the sources listed in a specified file, using the same syntax as for the -files switch.
--rule-file=filename: Load the given file as an LKQL rule options file (see LKQL Rule Files for more information). If not absolute, the provided path is relative to the current working directory.
-r, --rule [rule_name]: Enable the given rule_name for the current GNATcheck run; you can pass this option multiple times to enable more that one rule. Note that you can enable all rules by passing “all” as rule_name. You cannot provide parameters to a rule through this command-line option, to do so, please use an LKQL Rule Files.
--show-rule: Add the corresponding rule name to the diagnosis generated for its violation. If the rule has a user-defined synonym, both gnatcheck and user-defined rule names are used as rule annotation: [user_synonym|gnatcheck_rule_name].
--show-instantiation-chain: For reported generic instantiation constructs, display a chain of source location going from the generic unit to the instantiation.
--brief: Brief mode, report detections to Stderr. This switch also implies -q in terms of verbosity, and -s.
--check-redefinition: For a parametrized rule check if a rule parameter is defined more than once in the set of rule options specified and issue a warning if parameter redefinition is detected
--check-semantic: Check semantic validity of the source files by running gprbuild with the -gnatc switch, and report any legality error as part of the GNATcheck messages. By default, GNATcheck does not check that sources are semantically valid and will perform a best effort when encountering invalid source files. If you want to ensure and detect that your source files are valid as part of running GNATcheck, you should use this switch.
--charset=charset: Specify the charset of the source files. By default, ISO-8859-1 is used if no charset is specified.
--lkql-path=dir: Specify directory to add to the LKQL_PATH environment variable when GNATcheck is spawning the LKQL engine. You can specify this option multiple times to add multiple directories.
--rules-dir=dir: Specify an alternate directory containing rule files. You can specify this switch multiple times. Each of the directories specified will be scanned and all files with the extension .lkql will be loaded by GNATcheck to provide additional rules.
--include-file=file: Append the content of the specified text file to the report file
--emit-lkql-rule-file: Emit a file named rules.lkql containing the rule configuration of the current GNATcheck run. This file is emitted besides the given project file if there is one, otherwise, it is generated in the current directory. Be careful, if a rules.lkql file already exists, there will be an error.
-t: Print out execution time.
-v: Verbose mode; gnatcheck generates version information and then a trace of sources being processed.
-W, --warnings-as-errors: Treat warnings raised by GNATcheck as errors, ensuring an erroneous return code.
-o report_file: Set name of the text report file to report_file.
-ox report_file: Set name of the XML report file to report_file. Enforces -xml.
-rules rules_options: Provide rule options for the current GNATcheck run through the command-line. All switches and options provided after this flag will be parse as rule options.

Attention

This CLI section is deprecated, consider converting your rule configuration to the new LKQL rule file format using the --emit-lkql-rule-file switch.

If a project file is specified and no argument source is explicitly specified (either directly or by means of -files option), and no -U or --no-subprojects is specified, then the set of processed sources is determined in the following way. If root project file has attribute Main declared and all specified mains are Ada sources, then combined closure of those mains is processed. if root project does not have attribute Main declared, or at least one of the mains is not an Ada source, then all sources of non-externally built projects in the project hierarchy are processed.

If the argument project file is an aggregate project, and it aggregates more than one (non-aggregate) project, gnatcheck runs separately for each (non-aggregate) project being aggregated by the argument project, and a separate report file is created for each of these runs. Also such a run creates an umbrella report file that lists all the (non-aggregate) projects that are processed separately and for each of these projects contains the reference for the corresponding report file.

If the argument project file defines an aggregate project that aggregates only one (non-aggregate) project, the gnatcheck behavior is the same as for the case of non-aggregate argument project file.

2.2. The Check GPR Package

In addition to the command-line options, you can use attributes offered by the Check package to configure a GNATcheck run. In order to do this you may add the Check package in the GPR file you’re providing to GNATcheck through the -P command line options, example given:

project My_Project is
   package Check is
      ...
   end Check;
end My_Project;

Inside this package you can define the following attributes to configure GNATcheck:

Rules

Value is a list of rules to enable when invoking gnatcheck on this project. Values provided in this attribute behave as the ones provided with the --rule switch.

If the --rule switch is set when calling gnatcheck on a project file defining this attribute, then, values are concatenated.

Rule_File

Value is a path to a LKQL rule file. If not absolute, the path is relative to the project file that defines this attribute. See LKQL Rule Files for more information.

If the --rule-file switch is set when calling gnatcheck on a project file defining this attribute, then, an error is emitted and gnatcheck will exit with an error code.

Lkql_Path

Value is a list of directories to add to the LKQL_PATH environment variable when GNATcheck is spawning the LKQL engine. This variable is used to resolve module importations in LKQL sources. If not absolute, paths provided through this attribute are relatives to the project file defining it.

This attributes may work combined with the --lkql-path switch, in that case, all directories are added to the LKQL_PATH environment variable.

Switches

Index is a language name. Value is a list of additional switches to be used when invoking gnatcheck.

If a switch is provided in both command-line and Switches attribute, then, the value provided through the command-line is used.

Attention

There are several command-line switches that you cannot pass through the Switches attribute:

--version
--help
-P
-U
-Xname=value
-eL
-r, --rule [rule_name] (use Rules attribute instead)
--rule-file=filename (use Rule_File attribute instead)
--lkql-path=dir (use Lkql_Path attributes instead)
--target (use the Target GPR attribute instead)
--RTS (use the Runtime GPR attribute instead)

If you’re providing one of those switches through the Switches or the Default_Switches attribute, GNATcheck will emit an error message and exit with an error code.

Default_Switches

Same as Switches, but provided additional switches will apply only if there is no applicable Switches attribute.

2.3. Sources pre-processing

GNATcheck is handling Ada sources pre-processing, meaning that sources lines that are “excluded” by the Ada pre-processor are also ignored during the GNATcheck analysis. For example, given the following source:

procedure Main is
begin
   # if Foo = "Bar" then
   goto lbl;
   # else
   null;
   # end if;
end Main;

Running GNATcheck with the Goto_Statements rule enabled on this Ada code will flag the goto lbl; if, and only if, the preprocessor symbol Foo is set to "Bar".

To configure pre-processing, you can use the following GPR attributes:

Builder.Global_Compilation_Switches
Builder.Default_Switches
Builder.Switches
Compiler.Default_Switches
Compiler.Switches

Attention

There is a limitation to the GNATcheck’s pre-processing handling regarding conditioned with clauses. Meaning that no matter how symbols are defined, all with clauses are going to be analyzed and used by GNATcheck to resolve the closure of files to analyze.

2.4. LKQL Rule Files

You can configure GNATcheck rules using an LKQL file, provided through the --rule-file command-line option or implicitly fetched by GNATcheck (as described in the following paragraph).

By default, GNATcheck will look for a rules.lkql file besides the specified project file if any. If one is found and no other rule configuration has been provided (either through the LKQL –rule-file option, or by the now deprecated legacy -rules options), GNATcheck will load the rule configuration file as if it was provided by the –rule-file option.

Note

You can use the --emit-lkql-rule-file CLI switch to generate an LKQL rule file from a legacy rule configuration provided by the -rules section.

An LKQL rule file can be any valid LKQL file, the only requirement is that it must export a rules top-level symbol. This symbol defines an object value containing rules configuration; keys are GNATcheck rules to enable; and values are list of objects, each one representing an instance of the rule with its parameters. A rule parameter value can be of the boolean, the integer, the string, or the list of strings type, as shown in the simple example below:

val rules = @{
  Goto_Statements,
  Forbidden_Attributes: {Forbidden: ["GNAT"], Allowed: ["First", "Last"]}
}

Using the “@” object notation is strongly advised to make your configuration file way more understandable:

Please read the Predefined Rules documentation to view examples on how to provide parameters to rules through LKQL rule files.

Attention

You cannot provide the same key twice; thus, the following code will result in a GNATcheck error.

val rules = @{
  Forbidden_Attributes,
  Forbidden_Attributes: {Forbidden: ["GNAT"], Allowed: ["First", "Last"]}
}

If you want to create multiple instances of the same rule, you can associate a list value to the rule name in the rule configuration object. Elements of this list must be parameter objects containing an additional instance_name parameter defining the name of the instance described by the enclosing object. If none is provided, the instance is named after the rule it is instantiated from, as shown in the following example:

val rules = @{
  Goto_Statements,
  Forbidden_Attributes: [
    # "Forbidden_Attributes" instance of the "Forbidden_Attributes" rule, checking for 'First and 'Last
    {Forbidden: ["First", "Last"]},

    # "Length_Attr" instance of the "Forbidden_Attributes" rule, checking for 'Length
    {Forbidden: ["Length"], instance_name: "Length_Attr"}
  ]
}

Moreover, each instance must be identifiable through a unique name, thus the following configuration is invalid and will lead to a GNATCheck error:

val rules = @{
  Forbidden_Attributes: [
    {Forbidden: ["First", "Last"], instance_name: "Instance"},
    {Forbidden: ["Length"], instance_name: "Instance"},
  ]
}

Additionally to the rules top-level symbol, an LKQL rule file may export ada_rules and spark_rules symbols to enable associated rules, respectively, only on Ada code or only on SPARK code. Those symbols must also refer to an object value formatted like the rules value.

# Rules to run on both Ada and SPARK code
val rules = @{
  Goto_Statements
}

# Rules to run only on Ada code
val ada_rules = @{
  Forbidden_Attributes: {Forbidden: ["GNAT"]}
}

# Rules to run only on SPARK code
val spark_rules = @{
  Ada_2022_In_Ghost_Code
}

Please note that compiler based rules (Warnings, Restrictions and Style_Checks) cannot be restricted to Ada or SPARK code. Consequently, the following configuration will raise an error:

val spark_rules = @{
  Warnings: {Arg: "a"}
}

Attention

Instance uniqueness must also be respected between all rule sets, meaning that such config is invalid:

val rules = @{
  # Clashing with "Goto_Statement" in ada_rules
  Goto_Statements,

  # Clashing with "Forbid_Attr" instance in spark_rules
  Forbidden_Attributes: {Forbidden: ["GNAT"], instance_name: "Forbid_Attr"}
}

val ada_rules = @{
  Goto_Statements
}

val spark_rules = @{
  Forbidden_Attributes: {Forbidden: ["Length"], instance_name: "Forbid_Attr"}
}

You cannot provide more than one LKQL rule file when running GNATcheck. In order to compose a rule file with another you have to use the LKQL importation mechanism and combine rule objects. Here is an example of LKQL rule file composition:

# common_rules.lkql

val rules = @{
  Goto_Statements
}

# specific_rules.lkql

import common_rules

val rules = common_rules.rules.combine(
  @{ Redundant_Null_Statements }
)

Then you can run GNATcheck with the specific_rules.lkql file as coding standard to perform rules defined in common_rules.lkql combined to the ones defined in specific_rules.lkql.

Note

You can use the --lkql-path command-line switch and the Check'Lkql_Path GPR attribute to configure directories LKQL rule files are going to be searched in.

You can enable the same rule in multiple files, but the constraint about the instance name uniqueness remains valid, meaning that such configuration is invalid:

# common_rules.lkql

val rules = @{
  Forbidden_Attributes: {Forbidden: ["First"], instance_name: "Forbid_Attr"}
}

# specific_rules.lkql

import common_rules

val rules = common_rules.rules.combine(@{
  Forbidden_Attributes: {
    Forbidden: ["Last"],
    instance_name: "Forbid_Attr"
  }
})
# error: This rule configuration defines two instances with the same name: "Forbid_Attr"

2.5. GNATcheck Rule Options

Attention

Rules options are deprecated, consider converting your rule configuration to the new LKQL rule file format using the --emit-lkql-rule-file CLI switch.

The following options control the processing performed by gnatcheck. You can provide as many rule options as you want after the -rules switch.

+R[:instance_name:]rule_id[:param{,param}]

Create and enable an instance of the specified rule with the specified parameter(s), if any. rule_id must be the identifier of one of the currently implemented rules (use -h for the list of implemented rules). Rule identifiers are not case-sensitive.

Each param item must be a non-empty string representing a valid parameter for the specified rule. If the part of the rule option that follows the colon character contains any space characters then this part must be enclosed in quotation marks.

instance_name is a user-defined name for the created rule instance. If this is not specified, the instance name is set to the rule name (normalized to lower case). You can create as much instances as you want for a single rule, as long as they have distinct names (names aren’t case sensitive either). If an instance of the same rule with the same name already exists GNATcheck will raise an error.

For example:

--  Create and enable an instance of "Goto_Statements" named
--  "goto_statements".
+RGoto_Statements

--  Create and enable an second instance of "Goto_Statements" named
--  "custom_name".
+R:custom_name:Goto_Statements

--  Create and enable an instance of "Recursive_Subprograms" named
--  "other_name".
+R:other_name:Recursive_Subprograms

--  This will cause a GNATcheck error because the "goto_statement" instance
--  already exists.
+RGoto_Statements

This feature can be used to map gnatcheck rules onto a user’s coding standard.

-R[:instance_name:]rule_id

Remove the designated rule instance, disabling it at the same time.

Note

By removing a rule instance, all previously given instance parameter(s) are cleared from the GNATcheck memory.

Attention

No parameters are allowed for the -R rule option. Since rule instances are immutable, you cannot modify a parameter set once the instance has been created by a +R option.

-from=rule_option_filename

Read the rule options from the text file rule_option_filename, referred to as a ‘coding standard file’ below.

The default behavior is that all the rule checks are disabled.

If a rule option is given in a rule file, it can contain spaces and line breaks. Otherwise there should be no spaces between the components of a rule option.

If more than one rule option is specified for the same rule, with the same instance name, GNATcheck will raise an error and stop its execution.

Attention

Unlike in older versions of GNATcheck, rule instances aren’t mutable, so you cannot change options for an instance after its instantiation.

A coding standard file is a text file that contains a set of rule options described above.

The file may contain empty lines and Ada-style comments (comment lines and end-of-line comments). There can be several rule options on a single line (separated by a space).

A coding standard file may reference other coding standard files by including more -from=rule_option_filename options, each such option being replaced with the content of the corresponding coding standard file during processing. In case a cycle is detected (that is, rule_file_1 reads rule options from rule_file_2, and rule_file_2 reads (directly or indirectly) rule options from rule_file_1), processing fails with an error message.

If the name of the coding standard file does not contain a path information in absolute form, then it is treated as being relative to the current directory if gnatcheck is called without a project file or as being relative to the project file directory if gnatcheck is called with a project file as an argument.

2.6. Mapping GNATcheck Rules Onto Coding Standards

If you want to use GNATcheck to check if your code follows a given coding standard, you can use the following approach to simplify mapping your coding standard requirements onto GNATcheck rules:

when specifying rule configuration, use instance names that are relevant to your coding standard:

val rules = @{
  Gnatcheck_Rule_1: {instance_name: "My_Coding_Rule_1", param1: "value"},
  ...
  Gnatcheck_Rule_N: {instance_name: "My_Coding_Rule_N"}
}

or with the deprecated rule options:

+R:My_Coding_Rule_1:Gnatcheck_Rule_1:param1
...
+R:My_Coding_Rule_N:Gnatcheck_Rule_N

call gnatcheck with the --show-rule flag that adds the rule names the generated diagnoses. If a instance name is defined in the rule configuration, then this name will be used to annotate the diagnosis of the rule name:
```
foo.adb:2:28: something is wrong here [My_Coding_Rule_1|Gnatcheck_Rule_1]
...
bar.ads:17:3: this is not good [My_Coding_Rule_N|Gnatcheck_Rule_N]
```

Attention

A custom coding rule name can be any sequence of non-whitespace characters. Moreover, the “:” (colon) character is forbidden in those names for parsing purposes.

2.7. GNATcheck Exit Codes

gnatcheck returns the following exit codes at the end of its run:

0: No tool failure, no missing argument source and no rule violation was detected.
1: No tool failure, no missing argument source and at least one rule violation was detected.
2: A tool failure was detected (in this case the results of the gnatcheck run cannot be trusted).
3: No tool failure, no problem with rule specification, but there is at least one missing argument source.
4: Provided rule configuration file doesn’t exist.
5: The name of an unknown rule in a rule option or some problem with rule parameters.
6: Any other problem with specifying the rules to check.

If the exit code corresponds to some problem with defining the rules to check then the result of the gnatcheck run cannot be fully trusted because the set of rules that has been actually used may be different from user intent.

If gnatcheck is called with the --brief option, it will return the exit code 0 instead of 1 when some violation is detected (and no tool failure).

2.8. Format of the Report File

The gnatcheck tool outputs on stderr all messages concerning rule violations except if running in quiet mode. By default it also creates a text file that contains the complete report of the last gnatcheck run, this file is named gnatcheck.out. A user can specify generation of the XML version of the report file (its default name is gnatcheck.xml) If gnatcheck is called with a project file, the report file is located in the object directory defined by the project file (or in the directory where the argument project file is located if no object directory is defined), if --subdirs option is specified, the file is placed in the subdirectory of this directory specified by this option. Otherwise it is located in the current directory; the -o or -ox option can be used to change the name and/or location of the text or XML report file. This text report contains:

general details of the gnatcheck run: date and time of the run, the version of the tool that has generated this report, full parameters of the gnatcheck invocation, reference to the list of checked sources and applied rules (coding standard);
summary of the run (number of checked sources and detected violations);
list of exempted coding standard violations;
list of non-exempted coding standard violations;
list of problems in the definition of exemption sections;
list of language violations (compile-time errors) detected in processed sources;

The references to the list of checked sources and applied rules are references to the text files that contain the corresponding information. These files could be either files supplied as gnatcheck parameters or files created by gnatcheck; in the latter case these files are located in the same directory as the report file.

The content of the XML report is similar to the text report except that it explores the set of files processed by gnatcheck and the coding standard used for checking these files.

2.9. Rule Exemption

One of the most useful applications of gnatcheck is to automate the enforcement of project-specific coding standards, for example in safety-critical systems where particular features must be restricted in order to simplify the certification effort. However, it may sometimes be appropriate to violate a coding standard rule, and in such cases the rationale for the violation should be provided in the source program itself so that the individuals reviewing or maintaining the program can immediately understand the intent.

The gnatcheck tool supports this practice with the notion of a ‘rule exemption’ covering a specific source code section. Normally rule violation messages are issued both on stderr and in a report file. In contrast, exempted violations are not listed on stderr; thus users invoking gnatcheck interactively (e.g. in its GNAT Studio interface) do not need to pay attention to known and justified violations. However, exempted violations along with their justification are documented in a special section of the report file that gnatcheck generates.

2.9.1. Using pragma `Annotate` to control rule and instance exemption

Rule and instance exemption is controlled by pragma Annotate when its first argument is ‘gnatcheck’. The syntax of gnatcheck’s exemption control annotations is as follows:

<pragma_exemption>  ::= pragma Annotate (gnatcheck, <exemption_control>, <exempted_name> [, <justification>]);

<exemption_control> ::= Exempt_On | Exempt_Off

<exempted_name>     ::= <string_literal>

<justification>     ::= <expression>

An expression used as an exemption justification should be a static string expression. A string literal is enough in most cases, but you may want to use concatenation of string literals if you need a long message but you have to follow line length limitation.

When a gnatcheck annotation has more than four arguments, gnatcheck issues a warning and ignores the additional arguments. If the arguments do not follow the syntax above, gnatcheck emits a warning and ignores the annotation.

The exempted_name argument should be the name of some existing gnatcheck rule, or the name of a rule instance. Otherwise a warning message is generated and the pragma is ignored. If exempted_name doesn’t denote an activated rule or a valid instance in the given gnatcheck call, the pragma is ignored and no warning is issued. The exception from this rule is that exemption sections for Warnings rule are fully processed when Restrictions rule is activated.

Attention

Please not that for now it isn’t possible to provide an exempted name which designates an instance of a compiler-based rule (Warnings, Style_Checks and Restrictions) with a custom name.

A source code section where an exemption is active for a given rule is delimited by an exempt_on and exempt_off annotation pair:

pragma Annotate (gnatcheck, Exempt_On, "Rule_Name", "justification");
-- source code section
pragma Annotate (gnatcheck, Exempt_Off, "Rule_Name");

Using such annotations will exempt all violations of the rule designated by Rule_Name inside the exempted source section. But you can also provide the name of a rule instance to only exempt violations raised by this instance.

For some rules it is possible specify rule parameter(s) when defining an exemption section for a rule or an instance of it. This means that only the checks corresponding to the given rule parameter(s) are exempted in this section:

pragma Annotate (gnatcheck, Exempt_On, "Rule_Name: Par1, Par2", "justification");
-- source code section
pragma Annotate (gnatcheck, Exempt_Off, "Rule_Name: Par1, Par2");

A parametric exemption section can be defined for a rule if a rule has parameters and these parameters change the scope of the checks performed by a rule. For example, if you define an exemption section for ‘Restriction’ rule with the parameter ‘No_Allocators’, then in this section only the checks for No_Allocators will be exempted, and the checks for all the other restrictions from your coding standard will be performed as usual.

See the description of individual rules to check if parametric exemptions are available for them and what is the format of the rule parameters to be used in the corresponding parameters of the Annotate pragmas.

If a rule has a parameter, but its documentation does not explicitly say that the parameter can be used when defining exemption sections for the rule, this means that the parametric exemption cannot be used for this rule.

You may also use pragma GNAT_Annotate instead of pragma Annotate, this pragma has exactly the same format. This may be needed if you are using an old version of the GNAT compiler that does not support the format of pragma Annotate given above. Old GNAT versions may issue warning about unknown pragma when compiling a source that contains pragma GNAT_Annotate.

2.9.2. GNATcheck Annotations Rules

An Exempt_Off annotation can only appear after a corresponding ‘Exempt_On’ annotation.
An Exempt_On annotation should have a justification. Conversely, an Exempt_Off annotation should not have a justification.
Exempted source code sections are only based on the source location of the annotations. Any source construct between the two annotations is part of the exempted source code section.
Exempted source code sections for different rules are independent. They can be nested or intersect with one another without limitation. Creating nested or intersecting source code sections for the same rule is not allowed.
A matching ‘Exempt_Off’ annotation pragma for an ‘Exempt_On’ pragma that defines a parametric exemption section is the pragma that contains exactly the same set of rule parameters for the same exempted name.
Parametric exemption sections for the same rule with different parameters can intersect or overlap in case if the parameter sets for such sections have an empty intersection.
Malformed exempted source code sections are reported by a warning, and the corresponding rule exemptions are ignored.
When an exempted source code section does not contain at least one violation of the exempted name, a warning is emitted on stderr.
If an ‘Exempt_On’ annotation pragma does not have a matching ‘Exempt_Off’ annotation pragma in the same compilation unit, a warning is issued and the exemption section is considered to last until the end of the compilation unit source.

2.9.3. Using comments to control rule and instance exemption

As an alternative to the pragma Annotate syntax, it is also possible to use a syntax based on comments, with the following syntax:

<comment_exemption> ::= --## rule (on | off) <exempted_name> [## <exemption_justification>]

Here is an example:

--## rule off implicit_in ## Exemption justification
procedure Bar (A : Integer);
--## rule on implicit_in

Attention

Please note that a comment starting with --## but not respecting the above syntax will not trigger a warning, in order to not emit false positives. Also note that in its current iteration, this syntax does not support passing parameters to rule names

The rules mentioned in GNATcheck Annotations Rules are relaxed, in particular:

Justifications are not checked and are optional;
Anything between the exempted name and ## will be ignored;
Rules regarding parametric exemption do not apply, as per the notice above.

The rule on marker corresponds to Exempt_Off and rule off corresponds to Exempt_On. Apart from that, you can expect those rule exemptions to work in a similar fashion as the ones described above.

In addition, a shorthand syntax is available to exempt a rule just for one line:

<line_comment_exemption> ::= --## rule line off <exempted_name> [## <rule_justification>]

For instance, from the previous example:

procedure Bar (A : Integer); --## rule line off implicit_in ## Exemption justification

This will exempt the given rule or instance only for the line on which this comment is placed, and automatically turn it back on on the next line.

2.10. Using GNATcheck as a Known Problem Detector

If you are a GNAT Pro Assurance customer, you have access to a special packaging of GNATcheck called gnatkp (GNAT Known Problem detector) where the gnatcheck executable is replaced by gnatkp, and the coding standard rules are replaced by rules designed to detect constructs affected by known problems in official compiler releases. Note that GNATkp comes in addition and not as a replacement of GNATcheck.

You can use the command gnatkp --help to list all the switches relevant to GNATkp. GNATkp mostly accepts the same command arguments as GNATcheck and behaves in a similar way, but there are some differences that are described below.

The easiest way to use GNATkp is by specifying the version of GNAT Pro that you have and letting gnatkp run all known problem detectors registered for this version, via the switch --kp-version. For example:

gnatkp -Pproject --kp-version=21.2 --target=<my_target> --RTS=<my_runtime>

will run all detectors relevant to GNAT Pro 21.2 on all files in the project. The list of detectors will be displayed as info messages, and will also be listed in the file gnatkp-rule-list.out. The list of detected source locations will be generated on standard error, as well as in a file called gnatkp.out.

You can display the list of detectors without running them by specifying additionally the -h switch, e.g.:

gnatkp --kp-version=21.2 -h --target=<my_target> --RTS=<my_runtime>

You can also combine the --kp-version switch with the --target switch to filter out detectors not relevant for your target, e.g:

gnatkp -Pproject --kp-version=21.2 --target=powerpc-elf --RTS=<my_runtime>

will only enable detectors relevant to GNAT Pro 21.2 and to the powerpc-elf target.

Note that you need to have the corresponding target GNAT compiler installed to use this option. By default, detectors for all targets are enabled.

It is also possible to specify the custom list of detectors for GNATkp to run using the switch -r:

gnatkp -Pproject --target=<my_target> --RTS=<my_runtime> -r kp_xxxx_xxx [-r kp_xxxx_xxx]

where kp_xxxx_xxx is the name of a relevant known-problem to detect. You can get the list of available detectors via the command gnatkp -h. When combined with the --kp-version and possibly --target switches, gnatkp -h will only list the detectors relevant to the version (and target) specified.

Attention

You must provide explicit target and runtime (either through the command-line or with a provided project file) when running GNATkp to ensure the result soundness.

Note

The exemption mechanism is available for GNATkp as well but you have to change pragmas and comments a bit to avoid conflict with GNATcheck exemptions. Thus, pragmas annotations’ first argument must be gnatkp instead of gnatcheck:

pragma Annotate (gnatkp, Exempt_On, "kp_19198", "Justification");

And exemption comments’ first word must be kp instead of rule, example:

--## kp off kp_19198 ## Justification

You can check via the GNAT Tracker interface which known problems are relevant to your version of GNAT and your target before deciding which known problems may impact you: most known problems are only relevant to a specific version of GNAT, a specific target, or a specific usage profile. Do not hesitate to contact the AdaCore support if you need help identifying the entries that may be relevant to you.

2.11. Performance and Memory Usage

GNATcheck performances are closely related to rules you’re enabling and to the size of the codebase you’re running it on, and sometimes it can take a lot of time to perform all checks. You can use the -j switch to run GNATcheck in multi-core mode and decrease the checking time. However, you have to be careful about memory usage when running GNATcheck with this mode enabled:

You should count around 3.5 GB of available memory per million source code lines, per process. Meaning that for a project with l source code lines, if you run GNATcheck while providing n as parameter of the -j switch, you will need (l / 1,000,000) * 3.5 * n GB of available memory (this formula isn’t valid if n = 0).

Attention

Out-of-memory errors are hard to debug and can lead to system freezes, invalid results, or non-deterministic behavior. Thus, make sure you have enough memory before running GNATcheck.

2.12. Transition from ASIS-based GNATcheck

Originally gnatcheck was implemented on top of the ASIS technology and starting with version 23, it was re-implemented on top of the libadalang technology. This new implementation has kept most of the old gnatcheck interface and functionality, so transition from the old gnatcheck to the current version should be smooth and transparent, except possibly for a few aspects to be taken into account by users of the old technology.

2.12.1. Switches No Longer Supported

The following switches from the old gnatcheck are no longer supported:

-a: In order to process GNAT Run-Time library units, you need to explicitly include them in a project file.
--incremental: GNATcheck no longer makes the distinction between “local” and “global” rules, so this switch is no longer supported. You can use the -j switch instead which provides a significant speed up compared to the old version.
--write-rules=template_file: This switch is no longer supported. You can use the GNAT Studio rule editor instead to create a coding standard file.

2.12.2. The new rule instance system

The new gnatcheck implementation is introducing a new rule instance system which allows you to instantiate a rule multiple times under different names, and with potentially different rule parameters. You can now define more that one “alias” for the same rule to map your coding standard on the gnatcheck rules. However, rules aren’t mutable anymore, which means that you cannot modify parameters of a rule once it has been created (instantiated). For example:

--  The rule "Goto_Statements" is instantiated here
+RGoto_Statements

--  We try to create a new instance of the "Goto_Statements", this will fail
+RGoto_Statements:Only_Unconditional

While with the old system this rule file would just mutate the previously enabled “Goto_Statements” rule, with the new instance system, this will cause an error during the gnatcheck run, telling you that the “goto_statement” instance already exists. To correct this error, you have define a custom name for the second “Goto_Statements” instance:

--  The rule "Goto_Statements" is instantiated here
+RGoto_Statements

--  The rule "Goto_Statements" is also instantiated here,
--  under the "Uncond_Goto" name.
+R:Uncond_Goto:Goto_Statements:Only_Unconditional

The same way, you have to rewrite rule options such as:

+RForbidden_Pragmas:GNAT
+RForbidden_Pragmas:Annotate
+RForbidden_Pragmas:Assert

into a single rule option using the comma separated notation, like:

+RForbidden_Pragmas:GNAT,
                    Annotate,
                    Assert

This new instance system also suppress the possibility to disable a rule (or an instance) with a parameter. Thus, the -R rule option doesn’t accept parameters anymore.

2.12.3. Rule Aliases No Longer Supported

Because of historical reasons the old gnatcheck allowed aliases for some rules. These aliases are not documented, but there is some possibility that they could be used in some legacy rule files. GNATcheck no longer supports these aliases. Here is the (alphabetically ordered) list of all the aliases formerly accepted and their replacement:

Old Rule Alias	Replacement
Abstr_Types	Abstract_Type_Declarations
Bool_Relation_Ops	Boolean_Relational_Operators
Contr_Types	Controlled_Type_Declarations
Control_Structure_Nesting	Overly_Nested_Control_Structures
Decl_Blocks	Declarations_In_Blocks
Default_Par	Default_Parameters
Derived_Types	Non_Tagged_Derived_Types
Discr_Rec	Discriminated_Records
Explicit_Discrete_Ranges	Explicit_Full_Discrete_Ranges
Functionlike_Procedures	Function_Style_Procedures
Global_Loop_Exit	Outer_Loop_Exits
Goto	GOTO_Statements
Implicit_IN_Parameter_Mode	Implicit_IN_Mode_Parameters
LL_Subpr	Library_Level_Subprograms
Local_Pckg	Local_Packages
Misnamed_Identifiers	Identifier_Suffixes
Missing_Small_For_Fixed_Point_Type	Implicit_SMALL_For_Fixed_Point_Types
Non_Marked_BEGIN_In_Package_Body	Uncommented_BEGIN_In_Package_Bodies
Non_Named_Blocks_And_Loops	Unnamed_Blocks_And_Loops
One_Entry_In_PO	Multiple_Entries_In_Protected_Definitions
Parameter_Mode_Ordering	Parameters_Out_Of_Order
Positional_Component_Associations	Positional_Components
Positional_Generic_Associations	Positional_Generic_Parameters
Positional_Parameter_Associations	Positional_Parameters
Pragma_Usage	Forbidden_Pragmas
Predefined_Exceptions	Raising_Predefined_Exceptions
Proper_Returns	Improper_Returns
Qualified_Aggr	Non_Qualified_Aggregates
Restrict_Name_Space	Name_Clashes
Simple_Loop_Exit_Names	Expanded_Loop_Exit_Names
SPARK_Attributes	Non_SPARK_Attributes
Unconstr_Array_Return	Unconstrained_Array_Returns
Universl_Ranges	Universal_Ranges
Unreasonable_Places_For_Instantiations	Improperly_Located_Instantiations
Use_Pckg_Clauses	USE_PACKAGE_Clauses
Use_Of_Non_Short_Circuit	Non_Short_Circuit_Operators
Visible_Exceptions	Raising_External_Exceptions
Volatile_Requires_Addr_Clause	Volatile_Objects_Without_Address_Clauses

2.12.4. New Defaults For Recursive_Subprograms Rule

The Recursive_Subprograms rule now defaults to skipping dispatching calls and a new parameter Follow_Dispatching_Calls is available (the old Skip_Dispatching_Calls is still accepted for compatibility and is ignored since it’s the default). In addition, implicit calls made via default object initialization are not taken into account.

2.12.5. Argument Sources Legality And Project Files

The old gnatcheck compiled its argument sources to create the so-called ASIS tree files. This had two important consequences: first, gnatcheck could analyze only legal Ada sources, and second, for each legal argument source gnatcheck had full static semantic information. The situation with the current gnatcheck is different.

First, gnatcheck can now analyze Ada sources that are not legal, and it is trying to do its best to check the rules specified. This may result in false negatives caused by the absence of necessary semantic information or by some other problems in the argument source that impede a full check of some rules. You can use the --check-semantic option to check if your Ada sources are legal sources.

Second, if gnatcheck is called for some Ada source and it does not have a project file as a parameter, it will see only the information contained in the sources specified and will not follow the semantic dependencies on other sources if any. This is why it is strongly recommended to call gnatcheck with a project file. When called with a project file, gnatcheck follows all the semantic dependencies for sources located in the project file source directories.

2. Using GNATcheck

2.1. General GNATcheck Switches

2.2. The Check GPR Package

2.3. Sources pre-processing

2.4. LKQL Rule Files

2.5. GNATcheck Rule Options

2.6. Mapping GNATcheck Rules Onto Coding Standards

2.7. GNATcheck Exit Codes

2.8. Format of the Report File

2.9. Rule Exemption

2.9.1. Using pragma Annotate to control rule and instance exemption

2.9.2. GNATcheck Annotations Rules

2.9.3. Using comments to control rule and instance exemption

2.10. Using GNATcheck as a Known Problem Detector

2.11. Performance and Memory Usage

2.12. Transition from ASIS-based GNATcheck

2.12.1. Switches No Longer Supported

2.12.2. The new rule instance system

2.12.3. Rule Aliases No Longer Supported

2.12.4. New Defaults For Recursive_Subprograms Rule

2.12.5. Argument Sources Legality And Project Files

2.9.1. Using pragma `Annotate` to control rule and instance exemption
